Array Notation

Array notation extends vector notation to define arrays of higher rank, and namespaces, and lets these definitions span multiple lines:

• Parentheses embrace vector definitions and namespace name-value pairs
• Square brackets embrace higher-rank arrays
• Diamonds and linebreaks separate array elements and name-value pairs

Examples

Some examples of different kinds of arrays defined with array notation.

Nested Vector

      ⍴z← (0 6 1 8 ⋄ 2*0 2 0 2 1
      2 7 1 8 2 8 ⋄ 3 1 4 1 5)
4
      z
┌───────┬─────────┬───────────┬─────────┐
│0 6 1 8│1 4 1 4 2│2 7 1 8 2 8│3 1 4 1 5│
└───────┴─────────┴───────────┴─────────┘
      ('Three'
       'Blind'
       'Mice')
┌─────┬─────┬────┐
│Three│Blind│Mice│
└─────┴─────┴────┘

Matrix

      ⍴m←[0 6 1 8 ⋄ 1 4 1 4
       2 7 1 8 ⋄ 3 1 4 2]
4 4
      m
0 6 1 8
1 4 1 4
2 7 1 8
3 1 4 2

Short items are padded. (See Mix for details.)

      ⍴mice←['Three'
             'Blind'
             'Mice']
3 5
      mice,'|'
Three|
Blind|
Mice |

      ⍴RC←[0 'OK'
           1 'WS FULL'
           2 'SYNTAX ERROR'
           3 'INDEX ERROR'
           4 'RANK ERROR']
5 2
      ⍴expenses←0⌿[    ⍝ typed template matrix
      'Glasgow' 125.84
      ]
0 2

Column Matrix

      [ 1 ⋄ 2 ⋄ 3 ]
1
2
3
      (,⊂'Three') ≡ ('Three' ⋄)
1
      ⍴¨cm3←[('Three' ⋄)
             ('Blind' ⋄)
             ('Mice'  ⋄)]
5
5
4
      cm3
┌─────┐
│Three│
├─────┤
│Blind│
├─────┤
│Mice │
└─────┘

Rank-3 Array

      ⍴block←[
       [3 1 4 ⋄ 1 5 ]
       [2 7 0 ⋄ 2]
      ]
2 2 3
      block
3 1 4
1 5 0

2 7 0
2 0 0

Namespaces

Array notation allows you to write a namespace literal as zero or more name-value pairs, spanned by parentheses.

      ()                       ⍝ empty namespace
#.[Namespace]
      ()()                     ⍝ vector of empty namespaces
 #.[Namespace]  #.[Namespace]
      ( () ⋄ () )              ⍝ vector of empty namespaces
 #.[Namespace]  #.[Namespace]

      n←(x:'hello')
      n.x
hello

      m←(x:['hello'
        'world'])
      ⍴≢m.x                    ⍝ matrix
2

      (y:(x:'hello'))          ⍝ nested namespaces
#.[Namespace]

      (
        FirstName:'Wolfgang'
        LastName:'Mozart'
        Age:35
      )
#.[Namespace]

Scoping In Namespace Literals

Array and namespace literals can include value expressions.

      LUE←(answer:7×6)   ⍝ Life, the Universe, and Everything

Any expressions are evaluated in the scope around the namespace.

      long←'bobby'
      short←'jack'
      ns←(short:'jill' ⋄ inner:short∘.=short←3↑long)
      ns.inner
1 0 1
0 1 0
1 0 1
      short     ⍝ altered by inner assignment
bob
      ns.short  ⍝ unaffected by inner assignment
jill

Specification

The new syntactic forms were previously errors in every mainstream APL implementation and therefore introduce no backward incompatibilities.

In the following:

• A name-value pair is an APL name followed by a colon and a value expression.
• A separator is a diamond or line break, and separated means separated by them.
• An empty value expression or name-value pair is two separators with nothing but white space between them.

Namespace

A namespace is defined by a parenthesised, separated list of zero or more name-value pairs.

Empty name-value pairs define no namespace members.

Vector

A vector is defined by a parenthesised, separated list of two or more value expressions.

Empty value expressions define no vector elements.

Matrices And Higher-rank Arrays

An array of rank 2 or higher is defined by a bracketed, separated list of value expressions, which constitute the major cells of the array.

Short elements are padded to fill, and scalars are treated as length-1 vectors.

Information

Separators in a list of value expressions or name-value pairs make an enclosing parenthesis or bracket broken.

Separators encapsulated in a dfn or further contained in array notation do not break a parenthesis or bracket. For example, in

({1=⍵:'y' ⋄ 'n'}?2)

the diamond is part of the dfn and does not break the surrounding parenthesis.

Unsupported

The following are not supported by array notation:

• scripted and external objects
• non-array namespace members
• reference loops
• class instances
• internal representations returned by ⎕OR

While one can include the last three items when writing in array notation, they cannot be displayed in the notation.

Formal Syntax

The array notation can be described in this form, where expression is any traditional APL expression:

value ::= expression | list | block | space
list  ::= '(' ( ( value sep )+ value? | ( sep value )+ sep? ) ')'
block ::= '[' ( ( value sep )+ value? | ( sep value )+ sep? ) ']'
space ::= '(' sep? ( name ':' value ( sep name ':' value )* )? sep? ')'
sep   ::= [⋄#x000A#x000D#x0085]+

Figure 1: Syntax diagram
